SF6纯度分析仪中英文版

文章来源： 日期：2024-04-23

SF6纯度分析仪中英文版

产品简介

Product Introduction

The SF6 purity analyzer features a color LCD touch screen display, offering a user-friendly interface and ease of operation. It is equipped with imported high-precision sensors, designed for long lifespan, ensuring accurate and reproducible measurement results.

主要应用：故障定位，例行检测，气体净化，过滤监测，故障高压接点检查，SF6纯度检测。

Main Applications: Fault localization, routine testing, gas purification, filtration monitoring, high-voltage contact fault inspection, and SF6 purity detection.

产品特点

Product Features

● 4.3" TFT touch screen design

● 32-bit ARM MCU

● Separately designed air path and circuit

● Large capacity storage function

● Digital display of battery electric quantity

● Good repeatability and high response speed

● Automatic calibration of gradient

● Color LCD display

● Advanced probe protection function

● Anti-pollution and anti-disturbance capabilities

● High sensitivity and good stability

● Compact, beautiful, and easy to carry

技术参数

Technical Parameters

Measurement Range: Purity: 0 to 100%

Accuracy: Purity: ±0.5%

Resolution: Purity: 0.1%

Repeatability: Purity: ±0.5%

Pressure Range: 0 ~ 1MPa

Gas Flow Rate: 0.3 ~ 0.4L/min

Measurement Time: 5 minutes

Operating Principle: Infrared laser spectroscopic absorption principle

Operating Voltage: 110 ~ 220VAC, AC and DC dual use

Storage Temperature Rating: -25 ~ +70℃

Operating Environment: Temperature: -25 ~ +60℃

Lithium Battery: AC and DC dual-use, automatic switching, overcharge and over-discharge protection

Dimensions and Weight: 372×266.5×134.5 (mm), 3.5kg。

如果您对武汉鄂电电力试验设备有限公司的产品有进一步的咨询或购买意向，您可以拨打厂家直销热线：400-034-8088，或者访问他们的官方网址：www.cepee.cn。他们的专业团队将会为您提供更详细的信息和服务。
